INSTALLATION MANUEL INSTALLATION MANUAL
AG-FUTURE
GALEO
Illuminated RF Keypad
Automation for sliding gates
5] Dimensions

6] Wiring recommendations

4 x 0,75 mm
4 x 0,75 mm
4
erone.com
Operator with built-in
electronic panel
2 x 0,75 mm
Photocell RX
2
2 x 0,75 mm
2
3 x 1,5 mm ( LINE 230 Vac)
2
2
Photocell TX
2
EN
