ADEUNIS RF AMBIENT SENSOR - USER GUIDE - V1.1.1

1. Presentation

The Ambient sensor AMR from Adeunis RF is a temperature (room sensor) radio transmitter ready to use.
The Radio transmission complies with the wireless M-Bus protocol, which allows integration of this sensor into a consumption data recovery
architecture.

2. Device types

The Ambient sensor from Adeunis RF is available in following versions:
Ambient Sensor compact with
Ambient Sensor P/N
ARF8054AA
ARF8054BA
ARF8055AA
ARF8055BA

2.1. Sensor system

Thanks to the sensors, the Adeunis AMR Ambient sensors measure the ambient room temperatures.
In combination with high accuracy temperature sensors, the metering algorithm is able to achieve high precision temperature measurements

2.2. Measurements accuracy

Range of températures
from -30°C to -15°C
from -15°C to 0°C
from 0 to 70°C
from 70°C to 85°C
Important note : so as to preserve the life of the product, Adeunis RF recommends using the version with remote sensor when the tempera-
ture measurement to be performed is less than 0 ° C. The sensor can be placed in the «cold» area (exterior, chilled room, containers ...) and the
case in «temperate» zone.
1 integrated sensor
Specification
Compact version with 1 integrated sensor - T1 mode - no encryption
Remote sensor version with 1 integrated sensor and 1 remote sensor (cable 2.5m) - T1 mode - no encryption
Compact version with 1 integrated sensor - T1 mode - AES 128 encryption compliant OMS mode 5
Remote sensor version with 1 integrated sensor and 1 remote sensor (cable 2.5m) - T1 mode - AES 128
encryption compliant OMS mode 5
Accuracy
0.5°C
0.3°C
0.2°C
0.5°C
Ambient Sensor version remote
sensor with 1 integrated sensor
and 1 remote sensor
