Operating elements and display
5.4

Quick guide to the operating matrix

The following tables show all menus and the operating functions.
Display menu
F
AI1 Min-max-reset*
O
AI2 Min-max-reset*
O
CV1 Min-max-reset*
O
CV2 Min-max-reset*
O
Analog in 1
O
Analog in 2
O
Calc value 1
O
Calc value 2
O
Contrast
O
Brightness
O
Alternating time
O
Back
*) Is only displayed if "Allow reset" = "Yes" is set in the "Expert" menu for the corresponding channel.
Setup menu
F
Application
1-channel
2-channel
Diff-pressure
O
AI1 Lower range*
O
AI1 Upper range*
O
AI2 Lower range*
O
AI2 Upper range*
O
CV Factor*
O
CV Unit*
O
CV Bar 0%*
O
CV Bar 100%*
40
Description
Reset the min/max values for Analog in 1
Reset the min/max values for Analog in 2
Reset the min/max values for Calc value 1
Reset the min/max values for Calc value 2
Display setting for Analog in 1
Display setting for Analog in 2
Display setting for Calc value 1
Display setting for Calc value 2
Display contrast
Display brightness
Switchover time between values chosen to be displayed
Return to main menu
Description
Application selection
1-channel application
2-channel application
Difference pressure application
Lower measuring range limit for Analog in 1
Upper measuring range limit for Analog in 1
Lower measuring range limit for Analog in 2
Upper measuring range limit for Analog in 2
Factor for calculated value
Unit for calculated value
Lower limit for bargraph of calculated value
Upper limit for bargraph of calculated value
