User Manual
Model #06001
Thank you for choosing this product from
JessEm Tool Company. We appreciate your
support and hope that our product serves you
well. This product is designed to provide
many years of reliable service provided it is
used as intended and taken care of.
This user manual will assist you in assembly
and general operation of this product. It is
not our intent to teach you about
woodworking. It is assumed that you are an
experienced woodworker with the basic skills
and experience necessary to use this product
safely. If after reading the following
instructions, if you are unsure or
uncomfortable about safely using this
product we urge you to seek additional
information through widely available
woodworking books or classes.
Suggested Router Bit Speeds
Bit Diameter
1"
(25mm)
1-1/4" - 2"
(30-50mm)
2-1/4" - 2-1/2" (55-65mm)
3" - 3-1/2"
(75-90mm)
Slide™
Max. Speed
24,000 RPM
18,000 RPM
16,000 RPM
12,000 RPM
61 Forest Plain Road
Oro-Medonte, Ontario, Canada
L3V 0R4
Toll Free: 1-866-272-7492
Local: 705-726-8233
Fax: 705-327-0295
Email: jessem@jessem.com
Website: www.jessem.com
IMPORTANT!
Read and understand the contents of this
manual before assembly or operation of
this product.
As part of our Continuous Product
Improvement Policy, JessEm products are
always advancing in design and function.
Therefore there may be differences between
what is shown in our catalogs, website or at
retail display and what is sold at time of
purchase. We reserve the right to make
positive changes to our products at our
discretion.
The Mite-R-Slide is designed to fit the
JessEm Mast-R-Fence, JessEm Mast-R-
Fence II or JessEm Rout-R-Fence only.
We do not recommend or support the
application of our Mite-R-Slide to other
commercial or custom made fences and
therefore will not commit to resolving any
issues for applications other than our Mast-R-
Fence models #04001, #04010 and Rout-R-
Fence Model # 04100.
Publicité
Manuels Connexes pour JessEm Tool Mite R Slide 06001
Sommaire des Matières pour JessEm Tool Mite R Slide 06001
