Open Storage Side Cabinet
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Secure Your Furniture
Keep your home and family safe
with the wall anchor kit that is
included with the product.
Serious or fatal crushing injuries can
occur from tipping furniture.
WARNING: Manufacturer assumes no liability
for improper installation or excessive loads
placed on screws or bracket. This wall anchor
is not a substitute for proper adult supervision.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Visit: www.ameriwoodhome.com
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
B345811000COM1
Tough
You
Tube
Publicité
Manuels Connexes pour Signature Sleep 5811222COM
Sommaire des Matières pour Signature Sleep 5811222COM
- Page 1 5811222COM (Columbia Walnit) 5811341COM (Magnolia Oak) 5811900COM (Centralia Oak) Open Storage Side Cabinet B345811000COM1 Date of Purchase ___ / ___ / ___ Lot Number: Do Not Return This Product! Contact our customer service team for help first. Call: 1-800-489-3351 (toll free) Visit: www.ameriwoodhome.com...
