Linear PRO ACCESS MTR1 Mode D'emploi

MTR1
MTR3
PRO ACCESS
TM
1 and 3 Button Transmitter
Operation Instructions
GTO Access Systems, LLC
(800) 543-4283 • (850) 575-0176
www.gtoaccess.com
The visor clip can be installed for horizontal or vertical mounting. Slide the visor clip into one of the slots shown.
When the indicator light on the remote glows dimly, or fails to light at all when
the remote is activated, the battery needs replacing.
Follow the steps in the diagram and use caution to keep batteries away from
children.
Replace old battery with a fresh CR2032 Lithium battery.
Properly dispose of old batteries. Many electronic stores and supermarkets
have battery recycling bins.
Never dispose of batteries in fire because they could explode.
WARNING
KEEP BATTERIES OUT REACH OF CHILDREN. Swallowing batteries can lead to serious injury or death.
If you suspect someone has swallowed a battery, go to the hospital immediately. Do not induce
vomiting or eat or drink anything.
For more information, call the National Battery Ingestion Hotline: 202-625-3333.
The battery identification number for this product is CR2032.
The Linear PRO Access digital transmitter is a wireless radio control designed
for use with automatic garage and gate operators.
Each of the transmitter buttons will send a unique code when pressed. One
button can be used to activate the individual's garage door opener, a second
button can operate an access gate, a third button can activate an additional
garage door operator.
Linear PRO Access transmitters and receivers do not contain a typical "coding
switch". Each transmitter is permanently coded at the factory. The receiver is
programmed by "learning" a transmitter's unique digital code. The receiver will
activate only from the "memorized" transmitters.
The transmitter is powered by a Type CR2032 "coin-cell" battery. They should
last at least 1 year with normal use. The indicator light on the transmitter will
glow when the unit is activated. If the indicator lights dimly, or not at all when
transmitting, the battery needs to be replaced. To conserve battery life, an
internal timer limits the transmission duration to 20 seconds if a transmitter
button is held down.
VISOR CLIP INSTALLATION
REPLACING THE BATTERY
1
4
DESCRIPTION
This product is warranted to the consumer against defects in material and workmanship for one year from the date of purchase.
This warranty applies to first retail buyers of new devices. Warrantor will repair, or at its option, replace, any device it finds that
requires service under this warranty, and will return the repaired or replaced device to the consumer at the warrantor's cost. For
warranty service and shipping instructions contact warrantor at the address shown below. Devices must be sent to warrantor
for service at owner's expense. The remedies provided by this warranty are exclusive. Implied warranties under state law are to
the one year period of this written warranty. Some states do not allow limitations on how long an implied warranty lasts, so the
above limitation may not apply to you. In order to be protected by this warranty, save your proof of purchase and send copy with
equipment should repair be required. This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
All products returned for warranty service require a Return Product Authorization Number (RPA#). Contact Linear Technical
Service at 1-800-543-1236 for an RPA# and other important details.
2
3 Linear PRO Access radio controls provide a reliable communications link and fill an important need in portable wireless signaling.
However, there are some limitations which must be observed.
• For U.S. installations only: The radios are required to comply with FCC Rules and Regulations as Part 15 devices. As such, they
have limited transmitter power and therefore limited range.
• A receiver cannot respond to more than one transmitted signal at a time and may be blocked by radio signals that occur on or
near their operating frequencies, regardless of code settings.
• Changes or modifications to the device may void FCC compliance.
• Infrequently used radio links should be tested regularly to protect against undetected interference or fault.
5
6
• A general knowledge of radio and its vagaries should be gained prior to acting as a wholesale distributor or dealer, and these
facts should be communicated to the ultimate users.
WARNING: Changes, modifications or adjustments not expressly approved by GTO Access Systems, LLC could void the user's
authority to operate this equipment. There Are No User Serviceable Parts.
NOTICE: This device complies with part 15 of the FCC rules and with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Copyright © 2016 GTO Access Systems, LLC
Refer to the instructions provided with the garage door opener to set it
1
into "learn" mode.
• Press the opener's LEARN BUTTON for 1 second and release.
• The opener should BEEP and the LIGHT should BLINK once.
• The RED LED will remain lit in Learn Mode for 15 seconds.
While the RED LED is lit, PRESS and HOLD the transmitter's START/
2
STOP key until the opener BEEPS and the light BLINKS once.
PREPARING TO ADD OR REMOVE A REMOTE
1 PRESS THE
LEARN BUTTON
THE RED LED
WILL GLOW FOR
15 SECONDS
After programming, test the transmitter
BE SURE THE DOOR OR
from various locations. Be sure the
GATE AREA IS CLEAR!
door or gate areas are clear. Activate
the transmitter and verify that the
remote triggers the operator(s).
LIMITED WARRANTY
IMPORTANT !!!
2
PRESS THE DESIRED
REMOTE BUTTON
WHILE RED LED IS ON
Document Number: 10014570 REV A
