(24) SORTIE MONO
(25) EFFET SEND
(26) SORTIE MAIN
(27) INSERT L / R DROIT ET GAUCHE
(28) VOLUME TAPE OU USB
(29) VOLUME EFF RET
(30) VOLUME MONO
(31) BOUTON MAIN / TAPE
(32) LED PEAK
(33) VOLUME MAIN
(34) ENTRÉE TAPE (RCA PLUG - EN)
(35) SORTIE REC (RCA PLUG - EN)
(36) ROOM / PHONES (TRS 1 / 4 Jack)
(37) ROOM / PHONES (TRS 1 / 4 Jack)
(38) Alimentation fantôme + 48 V
(39) LED 2 x 9 SEGMENT
(40) LED DC-15V
(41) LED DC 15 V
(42) VOLUME ROOM
(43)
(44)
(44)
(43) + 48 V PHANTOM POWER
(44) AC POWER
(45) prise de courant AC
(46) USB
(45)
X 8 USB
w
USB
(46)
