Richell 94951 Manuel D'instructions

Thank you for choosing Richell's product. Please read this Instruction Manual carefully before
use, and use the product properly. Please also keep this manual intact and in a convenient
location for all to see and read. The figures used in this manual are to show operation method
or structure, and may look different from the actual product. If you give this product to someone
else, please also give this Instruction Manual to the new owner.
●
The door on this product will only swing one way and is designed to install in areas, such as
hallways, to keep cats (up to 11 lbs.) from escaping.
Please refer to Before Installation
●
The height of the product makes it harder for cats to jump over even with their strong feet.
●
This gate has no horizontal bars for cats to hook their feet.
●
Door feature allows users to pass through easily.
Before assembling this product, make sure the following parts are included:
Top Outer Frame Top Outer Frame Top Outer Frame
Bottom Outer Frame Bottom Outer Frame Bottom Outer Frame
① Openings with a height of 71.3" or more and width between 28.3" and 37.4". Extension set (sold separately) is available to expand
the Gate to 42.1".
② The area for Door to swing on the side where cats are contained must be level with no step or slope.
※ As the product is a tension-mount gate, please choose a wood pillar or a studs of a wall. The installation surface must be 3.9" or
more in width, straight, strong and flat.
※ Do not install the product in a location that does not have studs, such as veneer or drywall to prevent walls from being damaged.
28.5" - 37.5"
①
②
Instruction Manual
on page 6 for door opening directions.
Top Door Frame Top Door Frame Top Door Frame Top Door Slat Top Door Slat Top Door Slat
Bottom Door Frame Bottom Door Frame Bottom Door Frame Bottom Door Slat Bottom Door Slat Bottom Door Slat
71.5" or more
①
Wood Pillars Wood Pillars
(3.9" or more in width) (3.9" or more in width)
※ Use blueprint, stud finder, or contact your builder to find location of Studs.
Bolt Bolt Bolt
(16） (16） (16）
(8) (8) (8) Screw Screw Screw
(2) (2) (2)
Plate Plate Plate
Locking Member Locking Member Locking Member
(8) (8) (8)
Wall with Studs Wall with Studs
1
Extension Fixture Extension Fixture Extension Fixture
(8) (8) (8)
Top Extension Top Extension Top Extension
Adjuster Bolt Adjuster Bolt Adjuster Bolt
(4) (4) (4)
Adjuster Knob Adjuster Knob Adjuster Knob
(8) (8) (8)
Nut Nut Nut
(16) (16) (16)
Bottom Extension Bottom Extension Bottom Extension
Wall without Studs Wall without Studs
94951
(4) (4) (4)
(4) (4) (4)
0.6" or less in 0.6" or less in
depth depth
2.0" or more 2.0" or more
in height in height
Baseboard Baseboard
