DURAVIT D-Code DC 7105 Instructions De Montage
DURAVIT D-Code DC 7105 Instructions De Montage

DURAVIT D-Code DC 7105 Instructions De Montage

Publicité

Liens rapides

D-Code
Mounting instructions
74
35
120
4x
8x
16x
Instructions for use
The bathroom furniture range complies with the standards and guidelines applicable at the time of delivery and is designed for use in bathrooms.
Direct contact with water should be avoided, for example, when showering.
A power supply of 110 V – 230 V must be available on site.
Distance from the sensor to the reflecting surfaces = > 75 mm.
We reserve the right to make technical improvements and design modifications to the products illustrated.
MAL_D-Code_DC7105/24.05.1
74
35
B
120
A
2x 100
4x 5,5x50
4x 8
# DC 7105
A
B
mm
mm
650
432
