peerless-AV SMARTMOUNT SF632-S Mode D'emploi page 7

F ( 4 ) G ( 4 ) H ( 4 ) I ( 4 ) J ( 4 )
M4 x 12mm M4 x 25mm M6 x 12mm M6 x 25mm M8 x 12mm
K ( 4 ) L ( 4 ) M ( 8 ) N ( 8 )
M8 x 25mm M4 washer M6/M8 washer spacer
O (1) P (4) Q (4)
M5 x 6 mm washer
allen wrench
R (1)
adapter plate
