DPT-R-PLATE-01/02
Parts List
x4
M8 x 25mm
610825
x1
Radar Plate
4x 610825
Radar Plate
4x 60085
4x 60080
4x 60857
x4
M8 Nyloc nut
60080
x4
M8 Nut Cap
60857
30-10-17 Issue 1
x4
M8 washer
60085
Installation Instructions
Dual PowerTower®
Tools Required
8-10mm Flat Screwdriver
13mm Spanner
®
Publicité
Sommaire des Matières pour Scanstrut DPT-R-PLATE-01
- Page 1 Installation Instructions 30-10-17 Issue 1 DPT-R-PLATE-01/02 Dual PowerTower® Tools Required Parts List M8 x 25mm M8 Nyloc nut M8 washer 8-10mm Flat Screwdriver 13mm Spanner 610825 60080 60085 Radar Plate M8 Nut Cap 60857 4x 610825 Radar Plate 4x 60085...
- Page 2 IMPORTANT PowerTowers are only compatible with marine electronics devices as stated in the latest Scanstrut Product Guide – subject to change without prior notice. Use of the Power Towers with unapproved products, or overloading, invalidates any product warranty. Scanstrut does not supply fastenings to fix this product to the chosen surface. Please choose suitable fastenings for this purpose.
- Page 3 For help & information email: sales@scanstrut.com DPT-R-PLATE-01 tel: +44 (0) 1392 531280 268mm / 10.55” 233.10mm / 9.18” 214mm / 8.43” ®...
- Page 4 For help & information email: sales@scanstrut.com DPT-R-PLATE-02 tel: +44 (0) 1392 531280 203mm / 7.99” 170mm / 6.69” 142mm / 5.59” ®...
