Skan Holz Lugano Instructions De Montage

Lugano 420 x 380cm
Important information
We are pleased that you have chosen a product of SKAN HOLZ.
Please check the construction set for completeness using the position list in good time before starting construction or
commissioning your construction team. If individual parts are defective or missing, we will deliver these as quickly as possible.
However, we cannot refund the costs for any resulting construction delays to a construction company.
Please understand that we cannot assume any guarantee fort he following defects:
- incorrect storage before assembly
- incorrect anchoring with the ground or inadequate foundation (foundation according to statics)
- damage due to erection errors, e. g. the house is not level or not right-angled
- damage through a higher level of snow burden than statically envisaged. Recommendation: lad relief of the roof by remo-
ving the snow layer
- storm damage (insurance cases) or violent destruction
- damage through any alteration to the design by the client
- natural formation of cracks, branch holes, twisting, decolouration or similar modification (natural process; has no influence
on the statics)
Storage tips before assembly:
- store pallet on a level and dry surface.
- protect against sunshine and dampness; wood can warp drastically in a loose condition!
Maintenance tips:
The wood is untreated. Accordingly, regular, protective coating is absolutely necessary!
Please observe the attached information sheet "Care instructions/Colour treatment".
General tips and refers to:
General:
Windows and outside doors are supplied with insulating glass. Any additional insulation must be installed by the customer.
-
- The floor can be insulated by the customer. Please obtain relevant information from a specialist.
- Recommendation: predrill all screw holes!
- Regarding basic construction set:
- for tile roofing:
- Any optional roof insulation (in case of shingling and tile roofing) must be provided by the customer; please obtain relevant
information from a specialist. Shingles and tiles are not included in delivery.
- We recommend clearing the roof during heavy snowfall!
To the drawings:
-
1 Foundation according (to the structural calculations, not included in the scope of delivery): concrete C25/30, strip founda-
tion: w/h = 30/90cm, each 2 Ø 12 top and bottom, bow Ø 6, e < 20cm. Bottom panel: t=14cm,Q188A, top and bottom
throughout. Anchoring of the floor beams on the strip foundation using bolts M12, e < 60cm (by customer).
-
2 The thread rods to secure the house against storm are secured at the top with a washer and a nut, from below with a wa-
sher, spring and nut to tighten the upper nut of the thread rod without any problem, the spring at the bottom should be pres-
sed upwards with the thread rod. The spring may only be tightened slightly so that the house can work at the top. The
projecting ends of the thread rods have to be cut off at the top. Even after the house has been completed, attention
must always be paid to the fact that the thread rods are not seated on the floor as otherwise when it is dry, gaps can arise
and the roof is pressed upwards. The thread rods can also be pushed subsequently into the bores. You have to make sure
that each plank has a bore and that these are free and not blocked by shavings or similar.
-
3 In case of varying weather conditions, the wood alters in height (due to 'working'). To avoid the formation of joints, the planks
of the house may not, for example, be joined to one another through several block planks as then the wood can no lon-
ger expand.
-
The door and the window frames or their respective edging boards must not be fastened to the wall planks. If the
4
door cannot be closed properly, this can be adjusted by turning the hinges.
-
5 The sealing in the eaves area (block planks/roof boarding) must be provided by the customer. Suggestion without obliga-
tion: Use a permanently plastic jointing compound and a 1/4 strip for as sealing.
© SKAN HOLZ Europe GmbH D-21227 Bendestorf. Technical modifications reserved. All dimensions are approximate dimensions. 08/2023
Given that the roof is constantly exposed to the weather, a covering with only one
layer of roofing paper will not be enough over the long-term. An additional covering
with bitumen shingles, alternatively with a material of at least equivalent quality,
must follow.
a standard dimension for tile roofing was determined for calculating the roof lathing.
610853
610860
610877
1
EN
