BT7373
DESK MOUNT WITH ARTICULATED ARM
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Desk Mount
PLEASE KEEP THIS FOR FUTURE REFERENCE
REGISTERED DESIGN NO. 001713280-0040
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Product Dimensions..........................................................................................................................15
B-Tech Contact Details.....................................................................................................................16
INSTALLATION TOOLS REQUIRED
Crosshead
screwdriver
B-TECH AUDIO VIDEO MOUNTS
FEATURES
Designed for screens up to 24" (61cm) / 9kg (20lbs)
Fits screens with VESA mounting patterns:
75 x 75mm and 100 x 100mm
Optional desk clamp and grommet included
Easy tilt adjustment +/-40° tilt
Maximum extension is 457mm (18")
Features three swivel points: 360° at pole,
360° at both pivot points and 180° at interface
Simple installation with all mounting hardware included
CONTENTS
2.5mm Hex Key
(Supplied)
www.btechavmounts.com
4mm Hex Key
(Supplied)
