Filter Straw User Mannual
Product specifications
- Filter pore size: 0.1 um
- Weight: 3.2 oz
- Filtration technology: Activated carbon fiber, hollow fiber ultrafiltration membrane
- Filter Life: 100,000 gallons
Installation instructions
Upon first use or anytime the filter is dry, uncap both ends and stand it up in safe water(keeping mouthpiece
out of water abd dry) for 10 seconds to allow water to prime the filter. This will help the internal ultrafiltration
membrane get wet and water can be filtered more easily.
Straw
Directly put the filter straw
in water and sip it.
Bag
Squeeze
Install a standard water bag
filled with water on the inlet
of the filter straw.
Bag to bottle
Install a standard water bag filled with
water on the inlet of the filter straw and
a pop bottle with thread diameter 27.5mm
on the outlet.
Storage and maintenance
After drinking, frequently blow air through the mouthpiece or drain the filter straw by flinging it to keep it
clean. After using, remove the mouthpiece, flush it with clean water (standard water bag can be used or pop
bottle with thread diameter of 27.5mm can be filled clean water for backwashing the filter straw).
Bottle
Install a pop bottle with thread
diameter of 27.5mm on the inlet
of the filter straw
.
Squeeze
Hanging
Water Bag
Inline
Water bag and hose can be purchased
and matched with the filter straw
for better flow rate.
Caution:
Do not use chemicals to clean the filter straw, because they shorten the service life of carbon fiber filter
element.
Frequently asked questions:
Q: I have used it only once and it no longer works, why?
A: The product is not cleaned up after use, as a result its filter element is blocked. It should be repeatedly
backwashed to remove impurities on the surface of the ultrafiltration membrane.
Q: Why is there peculiar smell in second use?
A: After use, dirty residues are left in filter element. Please backwash the filter straw to remove dirty impurities on
the surface of the filtration membrane. Each time before using, the water filter straw should be backwashed to
avoid peculiar smell.
Q: Can I use this filter straw to filter saline water?
A: No, the filter straw can be used to filter fresh water rather than saline water
Q: Which kind of bottle can be matched with the filter straw?
A: The filter straw is matched with pop bottle with thread diameter of 27.5 mm in design, and therefore it can
only be matched with mineral water bottle with thread diameter of 27.5 mm to avoid any leakage.
Warning:
The Waterdrop filter straw is an individual water filtration device. It can be only used to filter water. If the product
is used beyond its normal service environment, we cannot guarantee the quality of filtered water
In order to prevent the damage of the filter, please do not thump it in any way. Do not throw the filter straw in
polluted water, Otherwise the filtration membrane wlll be polluted If you do not need to drink water,
please keep the mouthpiece of the water filter straw capped. If there is obvious damage to the straw filter, please
stop using it at once.
Manufacturer Technical Support
Tel: 1-888-352-3558 (U.S.)
E-mail: service@waterdropfilter.com
Made in China V001
Qingdao Ecopure Filter Co., Ltd.
