Symbiote ErgoStat Consignes D'installation

INSTALLATION INSTRUCTIONS
ErgoStat / Table Base Surface Mounting
Notes:
• Surface purchased separately
Hardware Pack: ETWPHP (p/n 93082504) or ESTBHP (p/n 93082503)
WARNING: Do not tighten the #10-12 surface screws more than 25 in-lbs. in laminated surfaces or 40 in-lbs. in
phenolic surfaces. Drill 1/8 " diameter pilot holes for laminated surfaces or
1
A. 24" deep Surface/Table Base
With the surface on the floor upside down if possible, position the brackets according to the dimensions
shown above for proper surface/base combination. The dotted circles indicate the holes that will be aligned in
the bracket and the surface for installing fasteners.
2
#10-12x3/4" screw
(96121301)
Insert (3) #10-12x3/4" pan head screws into the
bracket holes and tighten with #2 Phillips bit or
screwdriver. Repeat on opposite bracket.
p/n 08121103-01 rev E
A
B
B. 30" deep Surface/Table Base
ERGOSTATS AND TABLES
Required Tools:
• #2 Phillips Screwdriver and/or Phillips Bit
• Tape Measure
11 ⁄
6 4
C. 36" deep Surface/36" Table Base
3
position for box on Table Base
(ErgoStat shown)
ELECTRIC BASES ONLY - Surfaces do not have
predrilled holes for the control box. Position control
box and fasten with (3) #8-15x3/4" Phillips pan head
screws.
" diameter pilot holes for phenolic surfaces.
C
D
D. 30" or 36" deep Surface/ErgoStat Base
#8-15x3/4" screw
(06012501-02)
SYMBIOTE.COM
sheet 1 of 1
