TrueLine
RC536B
indoor
GEOMETRY
W5L57
W5L61
W5L113
W5L117
56
80
69
Not included
65
!
442710705848
© 02/2024 Signify Holding. All rights reserved
220 V
50Hz
4A
240 V
60Hz
MAX.
LUMEN
POWER [W]
18.5
20S
25S
17.8
34S
24.5
40S
29
40S
28
GLO W
IP20
IK02
WIRE
650 °C
EFFICIENCY CLASS
D
E
D
E
D
D
A+148
A
A+149
The light source of this luminaire is not
replaceable; when the light source reaches its end
of life the whole luminaire shall be replaced
1/12
Max.
35 °C
Min.
0 °C
A [mm]
kg
572
1.4
611
1.6
1132
2.4
1171
2.6
X = 64 mm (SAPP)
X= 46 mm (KLIMA)
Printed in Poland
Data subject to change without notice
Keep for future reference: www.philips.com/lighting
18
X
69
