REHOBOT DHSS100 Mode D'emploi page 25

D
A
B
C
D
Fig. 3.
REHOBOT Hydraulics AB Skjulstagatan 11 A, 632 29 Eskilstuna, SWEDEN P.O. Box 1107 631 80 Eskilstuna
T. +46 (0)16 - 16 82 00 F. +46 (0)16 - 13 93 16 info@rehobot.se www.rehobot.se
A
C
DHSS100 DHS150
mm in mm in
719 28.3 765 30.1
100 3.9 150 5.9
255 10 255 10
215 8.5 215 8.5
B
DHS180 DHS240
mm in mm in
785 30.9 804 31.7
180 7.1 240 9.4
255 10 255 10
215 8.5 215 8.5
Fig. 4.
Fig. 1.
Fig. 2.
