Oberon Smart
User manual
Thank you for purchasing the Lightpro Oberon Smart.
This document contains the required information for
correct, efficient and safe use of the product. Consult the
general manual of the Lightpro 12-volt system and the
user manual of your transformer for more information
about the set up and connection of your light plan.
Read the information in this manual carefully before
using the product. Keep this manual near the product for
consultation in the future.
PRODUCT DESCRIPTION
The Lightpro Oberon Smart is a standing LED lamp
for outdoor use. The fixture can be mounted on a solid
surface or placed in the ground with the supplied spikes.
This product may only be used as outdoor lighting in
combination with the Lightpro 12-volt system. Any
alterations made to the product may have consequences
for the safety, guarantee and correct functioning of the
product and/or other parts of the system.
SPECIFICATIONS
Product
Article number
Light source
Power
Luminous flux
Average lifetime
Dimensions (H x Ø)
Protection class
Ambient temperature
Cable length
Dimmable
Replaceable light source
PACKAGING CONTENT
[Figure A]
1 Fixture Oberon Smart
2 Ground spike
3 Screw
4 Screw
5 Plug
6 Lightpro connector
7 Hex key
Check if all parts are present in the packaging. For
questions about parts, service, and any complaints or
other remarks, you can always contact us.
E-mail: info@lightpro.nl.
8
Lightpro Oberon Smart
199N
LED 5W AC/DC 12V
5W
280 lm
25.000 Hours
665 x 64 mm
IP44
-20 °C to 50 °C
1m
Yes
Yes
ZIGBEE
The products can communicate with each other via
Zigbee, giving you an endless range. The maximum
distance between two products is 20 meters.
For the Lightpro SMART system to work properly, the
transformer must be on continuously (do not use a light
sensor or other accessories).
PAIRING LIGHT
1. A Gateway is required for pairing a light fixture.
2. Turn on the light fixture closest to the Gateway.
3. Add the light source to the app: click '+' and select the
light source (Zigbee).
4. Enter a logical light-fixture name.
Optional: turn on the second-nearest light fixture and
repeat the above steps.
HOW TO REST THE OBERON SMART
Disconnect the light from the main cable for 2 seconds.
Then reconnect the light to the main cable. Repeat this
3 times.
