KPS Installation Manual
Special Safety Instructions:
Standard Specific Safety Instructions:
Whilst all individual outputs are classed as SELV outputs in accordance with the standard IEC/EN/UL/CSA60950-1
(<60Vdc or 42.4V peak), seriesed combinations of these outputs may exceed these
values and become hazardous output voltages.
If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment
may be impaired.
Environmental Specifications:
Description Operation Storage
Use Indoor -
Temperature 0°C - +70°C (derating at 2.5%/°C from 40°C) -20°C - +85°C
Humidity 10 - 95% RH, non-condensing 10 - 95% RH, non-
condensing
Altitude 2000M 2000M
Orientation See Fig 1 ALL
Material Group IIIb
Pollution Degree 2
IP Protection Class IP20
Level of Insulation:
Dielectric Strength testing is carried out as follows:
Primary mains circuits to secondary: 3kVAC, 4142VDC
.Safety Approvals:
nd
UL/cUL60950-1 (2 Edition)
nd
IEC / EN60950-1(2 Edition)
CE marking when applied to any KPSxx-yy product indicates compliance with the Low Voltage Directive
nd
(2006/95/EC) in that it complies with EN60950-1 (2 Edition).
Fusing: Internal fuses (F1): Single fuse in the L line, T1A, 250V,
Input Connection
ACN – Neutral ACL – Live
KPS5 –xx KPS10-xx KPS15-xx
