APT 6001
SPT1001
APT 6002
SPT1002
APT 102S
SPT1004
SPT1005
Parts List
Power Tower
x1
x1
Blanking Cap
(APT6002 only)
101807
ø50mm (2")
ø8.5mm (21/64")
4x
APT 5U
APT 10U
APT 19000
APT 19001
Cable Grommet
(Blanked)
101817
x1
Cable Grommet
101806
x
x1
Nylon Shoulder
Washer
64000
Foam Base
Seal
101817
101806
M8 x 25+
4x
64000
4x
x
Installation Instructions
Aluminium/Stainless Steel PowerTower
Tools Required
Hole Saw
ø50-52mm (2")
Power drill
ø8.5mm (21/64") Drill Bit
x4
Parts Required
x1
Model
SPT 1001
SPT 1002
SPT 1004
SPT 1005
APT 6001
APT 6002
APT 102S
APT 5U
APT 10U
APT 19000
APT 19001
INSTALLATION SOLUTIONS FOR MARINE ELECTRONICS
M8 x 25mm+
x4
x
127mm (5")
127mm (5")
152mm (6")
152mm (6")
150mm (5.9")
150mm (5.9")
127mm (5")
127mm (5")
127mm (5")
127mm (5")
127mm (5")
®
Publicité
Manuels Connexes pour Scanstrut SPT 1001
Sommaire des Matières pour Scanstrut SPT 1001
- Page 1 64000 Cable Grommet Blanking Cap Parts Required (APT6002 only) Foam Base M8 x 25mm+ Seal 101807 101806 Model SPT 1001 127mm (5”) SPT 1002 127mm (5”) SPT 1004 152mm (6”) SPT 1005 152mm (6”) APT 6001 150mm (5.9”) APT 6002 150mm (5.9”)
- Page 2 IMPORTANT Power Towers are only compatible with marine electronics devices as stated in the latest Scanstrut Product Guide – subject to change without prior notice. Use of the Power Towers with unapproved products, or overloading, invalidates any product warranty. Scanstrut does not supply fastenings to fix this product to the chosen surface. Please choose suitable fastenings for this purpose.
