- Page 1 ® Intel Express 140T Standalone Hub Quick Start and User Guide Get other manuals https://www.bkmanuals.com...
- Page 2 Copyright © 1998, Intel Corporation. All rights reserved. Intel Corporation, 5200 NE Elam Young Parkway, Hillsboro OR 97124-6497 Intel Corporation assumes no responsibility for errors or omissions in this manual. Nor does Intel make any commitment to update the information contained herein.
- Page 3 Cabling Devices ..................8 Media Requirements ..............8 Straight-through vs. Crossover Cables .......... 8 Testing Cables ................8 Troubleshooting ..................10 Regulatory Information ................ 11 Warnings ....................12 Limited Hardware Warranty ..............15 Intel Customer Support ..........Inside Back Cover Get other manuals https://www.bkmanuals.com...
- Page 4 Traf fic en = 100 100 Mbp Off = 10M Mbp s ® • Install the Intel Express 140T Cla ss Standalone Hub in a rack or on a shelf. Shelf: Peel off the protective backing and attach the rubber •...
- Page 5 User Guide - Overview Features This guide covers both the 16- and 24-port versions of the Express 140T Standalone Hub. 16-port 140T Hub (Product Code EE140TX16) ® Intel Express 140T Collisions Power 10Mbps 100Mbps Standalone Hub Solid green = Link...
- Page 6 Understanding 140T Hubs Port LEDs On the 140T, the port LEDs are located on a common panel with the hub LEDs. These LEDs indicate port status, individual port speed, and port activity. Solid green = Link Top rows: Port Blinking green = Activity Activity Port Activity Orange = Autodisabled...
- Page 7 The 140T hub LEDs are located above and below the port LEDs. These LEDs indicate the condition of the power supply, collisions per segment, and the amount of traffic per segment. ® Intel Express 140T Collisions Power 10Mbps 100Mbps Standalone Hub...
- Page 8 A bridge allows two segments to communicate with each other. Typically, a bridge connects segments operating at different speeds. The 140T contains an internal bridge that automatically allows devices operating at 10Mbps to communicate with devices operating at 100Mbps. Intel ® Express 140T Collisions Power 10Mbps 100Mbps 10Mbps Hub...
- Page 9 • Only two hubs (ClassII) can be daisy-chained together. • The maximum cable length connecting the hubs can’t exceed 5 meters. 100m (max) 5m (max) 100m (max) Intel ® Express 140T Collisions Intel ® Express 140T Collisions Standalone Hub Power...
- Page 10 Cabling Devices Media Requirements Incorrect cabling is often the cause of network configuration problems. Read the next two pages if you’re unsure of your requirements. 100Base-TX The 100Base-TX Fast Ethernet specification requires that you use CAT 5 UTP cabling to operate at 100Mbps. If you use lower grade cabling (CAT 3 or CAT 4), you may get a connection, but will soon experience data loss or slow performance.
- Page 11 However, if the LEDs remain off, you probably have a bad cable. If a cable passes either of these tests, but the network connection is slow, verify that wires 1 & 2 and 3 & 6 on the cable are twisted pairs. Refer to the following diagrams.
- Page 12 Troubleshooting Can I daisy-chain a 100Mbps hub to the 140T hub with UTP cabling? Yes. The 140T is a Class II device so you can daisy-chain two hubs operating at 100Mbps a maximum of 5m. How do I get devices running at 10Mbps to talk to devices running at 100Mbps? The 140T hub’s internal bridge allows 10Mbps and 100Mbps segments to communicate with each other automatically.
- Page 13 Manufacturer Declaration This certifies that the Intel® Express 140T Standalone Hub complies with the EU Directive 89/336/EEC, using the EMC standards EN55022 (Class A) and EN50082-1. This product also meets or exceeds EN 60950 (safety) requirements.
- Page 14 This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Internal access to Intel Express Standalone Hubs is intended only for qualified service personnel. Do not remove any covers.
- Page 15 · keine starken, von elektrischen Geräten erzeugten elektromagnetischen Felder aufweisen; · in Regionen, in denen elektrische Stürme auftreten, mit einem Überspannungsschutzgerät verbunden sein; während eines elektrischen Sturms sollte keine Verbindung der Telekommunikationsleitungen mit dem Modem bestehen; · mit einer geerdeten Wechselstromsteckdose ausgerüstet sein. Versuchen Sie nicht, das mitgelieferte Netzkabel zu ändern oder zu verwenden, wenn es sich nicht um genau den erforderlichen Typ handelt.
- Page 16 Wichtige Sicherheitshinweise 1. Bitte lesen Sie sich diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den spätern Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Vervenden Sie keine Flüssig- oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur Reinigung. 4.
- Page 17 (RMA) number either to the company from whom you purchased it or to Intel (North America only). If you ship the product, you must assume the risk of damage or loss in transit. You must use the original container (or the equivalent) and pay the shipping charge.
- Page 18 (RMA) number either to (a) the company from whom you purchased it or (b) to Intel, North America only (if purchased in Europe you must deliver the product to “(a)”. If you ship the product, you must assume the risk of damage or loss in transit.
- Page 19 à l’exception des cas énumérés ci-après, à condition que le produit soit renvoyé avec un numéro d’autorisation de retour du matériel (ARM) à (a) la société auprès de laquelle il a été acheté ou (b) à Intel, en Amérique du Nord seulement (si l’achat a eu lieu en Europe vous devez le renvoyer à...
- Page 20 È necessario utilizzare l’imballaggio originale del prodotto (o un suo equivalente) e pagare le spese di spedizione. Intel sostituirà o riparerà il prodotto (o la parte) con uno nuovo o uno rifabbricato, e il prodotto restituito diventerà...
- Page 21 übernehmen. Intel ersetzt die Hardware entweder durch ein neues oder ein neuwertiges Produkt. Das zurückgegebene Hardwareprodukt wird Eigentum von Intel. Intel garantiert, daß das reparierte oder ersetzte Hardwareprodukt für einen Zeitraum von: (i) neunzig (90) Tagen ab Rückgabedatum oder (ii) für die verbleibende Zeit der ursprünglichen Garantie von drei (3) Jahren frei von Material- und Herstellungsfehlern ist.
- Page 22 (RMA), a (a) la empresa a la que se adquirió o (b) a Intel, sólo en América del Norte (si lo adquirió en Europa, debe entregar el producto a “(a)”. Si envía el producto, debe asumir el riesgo de daños o pérdida en el transporte.
- Page 23 Intel Customer Support Automated Support You can reach Intel’s automated support services 24 hours a day, every day at no charge. The services contain the most up-to-date information about Intel products. You can access installation instructions, troubleshooting information, and general product information.
