Step10 :
Insert C-A clip into the curved notch of the arm set.
Step 11 :
Install C-C sleeve into the hole of the arm set. (Note the sleeve gap location)
Step 12 :
Set the arm set into the wall mount set, and tighten the arm set with C-B screw.
C-B
A-A
All manuals and user guides at all-guides.com
Wall Mount Installation Guide
C-A
C-C
2
1
7
The gap should be on the
opposite side to C-A clip
