Traxon PXL Distributor Pro 8 Instructions De Montage

PXL Distributor Pro 8 (AM461810055)
P 1
2
P 1
P 2
Mounting
www.traxon-ecue.com
Mounting Guide
13.39"
418.00mm
Allegro Dot XS PXL Distributor Pro 8
16.46"
9.00mm
0.35"
340.00mm
13.39"
418.00mm
288.00mm
16.46"
11.34"
9.00mm
392.00mm
0.35"
15.43"
354.00mm
13.94"
P 3 P 5 P 7
P 2 P 4 P 6 P 8
288.00mm
11.34"
392.00mm
15.43"
354.00mm
13.94"
47.4mm / 1.87"
P 3 P 5 P 7
P 4 P 6 P 8
Outdoor power cable options (provided by others):
SJTW 16AWG x 3C
SJOW 16AWG x 3C
H05RN-F 3 x 1.0mm2
Cable OD ɸ6.5 - 9.5mm
M8 (4X, by others)
Mounting Guide
3PIN FIELD INSTALLABLE CONNECTOR PD8 IP67 (AM461770055)
-Solder type field-installable connector
47.4mm / 1.87"
2
Outdoor power cable options (provided by others):
SJTW 16AWG x 3C
SJOW 16AWG x 3C
H05RN-F 3 x 1.0mm2
Cable OD ɸ6.5 - 9.5mm
IMPORTANT:
for the last data injector in a chain,
use end cap to seal the D ATA OUT connector.
Tightening torque: 0.9Nm.
08/23 V1.1
Wire# Description
Live
1
Neutral
2
3 Earth
Mount on smooth and rigid surface.
Do not submerge.
©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED.
1 of 2
