RK5001ek INSTRUCTIONS
RK5001ek Product Inventory
Horizontal Waterfall Manager (1)
10-32 x 1/2" (13mm) Screw (2)
10-32 Wing Nut (2)
Instructions
1. Locate the two mounting holes inside the rear top cross bracket of your Enclosure.
2. Line up your waterfall manager and place 10-32 screws through the mounting holes.
3. Start the wing nut and tighten.
Belkin Tech Support
Europe: 00 800 223 55 460
For other languages: www.belkin.com/support
RK5001ek Instructions
Rear of Enclosure
10-32 x 1/2" (13mm)
Screw
EN
DE
FR
P35753ec
