FCC Information
•
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician
for help.
Changes or modifi cations not expressly approved by
Audiovox could void the user's authority to operate the
equipment.
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
Before you begin
Plugging in for power
•
Connect the supplied power adaptor to the unit's Power
jack, and connect the other end to a convenient wall
outlet.
•
Once connected with power, the clock fl ashes. Refer to
the Clock section for instructions on properly setting the
Clock.
Battery back-up operation
•
This clock radio is equipped with a timekeeping system
that can be powered with a 9-volt alkaline battery (not
included). The power failure protection circuit will not
operate unless battery is installed.
•
When normal household power is interrupted, or
AC adaptor
is unplugged, the
y
clock radio to keep track of time and alarm settings
programmed into memory.
•
When the battery backup functions, the digital display
will not light, however, the function of alarm still occurs
during the power interruption if remaining battery
power is adequate.
l
•
Normal operation will resume after AC power is
restored so you will not have to reset the time or the
alarm.
To install the battery:
1. Remove battery compartment door (located at the
bottom of the radio) by applying thumb pressure to the
tab on battery door and then lift the door out and off
the cabinet.
2. Connect a 9-volt alkaline battery (not included) to the
connector plug.
3. Replace the compartment door.
Warranty information
12 Month Limited Warranty
Applies to RCA Clock Radios
AUDIOVOX ACCESSORIES CORP. (the Company) warrants
to the original retail purchaser of this product that should
All manuals and user guides at all-guides.com
AC/
battery
will power the
Before you begin
Power failure indicator
If you have not installed the
product, or the
battery
runs out while
disconnected, all the settings (clock and alarm) will be lost.
After
AC/AC adaptor
is reconnected, the Digital Display will
fl ash to indicate that power was interrupted and you should
readjust the time settings.
Alkaline (NEDA 1604A/IEC 6LR61) battery
is recommended. Carbon-zinc battery may
be used but memory holding time will be
substantially reduced. Memory holding
time for a fresh alkaline battery is approximately 8
hours (if alarm is not operated) which should take
care of short, nuisance-type AC power failures. To
preserve battery life, the unit should remain plugged
into an AC outlet. As the battery gets older, its
voltage drops and memory may be lost. Be sure to
replace the battery periodically. Battery should be
removed if the unit will be stored for more than
one month.
A leaky battery
clock radio.
General controls
Top view
ON/OFF – Turn the unit on/off
REV/FWD
– Adjust clock time
SNOOZE – Turn off the wake function momentarily
(9 minutes); turn off the current sleep timer
WAKE –
OFF – Activate or change alarm settings
/WAKE1/WAKE2/
– Slide switch to set Wake 1,
Wake 2 and clock time
NAP – Activate nap function
SLEEP – Activate sleep function
Some states do not allow limitations on how long an implied
warranty lasts or the exclusion or limitation of incidental or
consequential damage so the above limitations or exclusions
may not apply to you. This Warranty gives you specifi c legal
rights and you may also have other rights which vary from
9-volt alkaline battery
in the
AC/AC adaptor
is
can badly damage the
