Manuels Connexes pour Vantage Point VSS-B
Sommaire des Matières pour Vantage Point VSS-B
- Page 1 Small Swing Mount VSS-B PEQUEÑO PETIT KLEIN Montaje de Oscilación Mont de Balancement Schwingen-Gestell Screen Size Range: Max Weight Load - Monitor Mount: Hole Pattern Range: 10 - 26 in. 40 lbs / 18 kg VESA® 75 x 75mm...
- Page 2 Concrete only Use with 200mm VESA Patterns Instrumentos Tools Instruments Werkzeuge 3/8” or 10mm 5/32 or 4mm...
- Page 3 Brick Wall installation. Preview all steps before beginning. Should any portion of these instructions be unclear, contact us directly at 800-582-9595 or by email at support@thinkvp.com for assistance. Do not attempt to assemble this Vantage Point Mount System, if you have any doubts as to its proper assembly and installation.
- Page 4 Installation and Assembly TV Mounting Hardware Kit Hardware Kit TV que Monta equipo de Hardware Instalación y equipo de Hardware de Asamblea Installation et kit de Matériel d’Assemblage TV Montant le kit de Matériel Fernsehen, das Hardware-Bastelsatz Besteigt Installierung und Zusammenbau-Hardware-Bastelsatz #14 X 2-1/2”...
- Page 5 Clavo de Madera Clou de Bois Wood Stud Holz Knopf 16” 4X - Ø 5/32” X 2-1/2” DEEP Ø 4mm X 6.35 cm 40.64 cm 16” 40.64 cm Go to Install Monitor Step Vaya para Instalar Paso de Monitor Allez Installer le Pas de Moniteur Gehen Sie, um Monitor-Schritt Zu installieren...
- Page 6 Concreto Béton Concrete Beton 3X - Ø 3/8” X 2-1/2” DEEP Ø 10mm X 6.35 cm Go to Install Monitor Step Vaya para Instalar Paso de Monitor Allez Installer le Pas de Moniteur Gehen Sie, um Monitor-Schritt Zu installieren...
- Page 7 Instalar el Monitor de Monte Installez le Mont de Moniteur Install Monitor Installieren Sie Monitor-Gestell 4m x12m 4m x16m 6m x12m 6m x16m 75mm 100mm 75/100mm VESA 75mm 100mm 200mm 200mm 200mm 100mm 4X - 4MM SCREWS 200mm VESA 4X - 6MM SCREWS 200mm VESA shown...
- Page 8 Instalar el Monitor de Monte Installez le Mont de Moniteur Install Monitor cont’d Installieren Sie Monitor-Gestell Back View Back View 100mm VESA shown 100mm VESA shown Back View Back View 100mm VESA shown 100mm VESA shown...
- Page 9 Ajuste Ajustage Adjustment Anpassung Tension Adjust Adjuste de Tensión Réglage de la tension Spannung einstellen ? + - ? + - Tilt Adjust Rotation / Level Adjust Ajuste de Rotación / Nivel Ajuste de Inclinación Réglage de I’nclinaison Réglage de la rotation / de la hauteur Kippwinkeleustellung Drehung / Nivellierung einstellen...
- Page 10 VANTAGE POINT PRODUCTS CORP. P.O. BOX 2485 SANTA FE SPRINGS CA 90670 USA TEL: 1.800.582.9595 FAX: 562.946.3898 EMAIL: support@thinkvp.com CANADA TEL: 905.607.9994...
