Models/Modelos/Modèles
P130LF, P131LF, P135LF, P135LF-W,
P136LF, P136LF-M, P138LF-M
Series/Series/Seria
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
You may need / Usted puede necesitar / Articles dont vous pouvez avoir besoin
For easy installation of your
Peerless
faucet you will need:
®
• To READ ALL the instructions completely
before beginning.
• To READ ALL warnings, care, and maintenance
information.
• To purchase the correct water supply hook-up.
Para instalación fácil de su llave
Peerless
usted necesitará:
®
• LEER TODAS las instrucciones completamente
antes de empezar.
• LEER TODOS los avisos, cuidados, e
información de mantenimiento.
• Comprar las conexiones correctas para el
suministro de agua.
Pour installer votre robinet
Peerless
facilement, vous devez:
®
• LIRE TOUTES les instructions avant
de débuter;
• LIRE TOUS les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien;
• Acheter le bon nécessaire de raccordement.
?
1-800-438-6673
www.peerlessfaucet.com
10/09/2018
SINGLE HANDLE LAVATORY FAUCET
86583
LLAVE DE LAVAMANOS DE UNA MANIJAS
ROBINET À UNE MANETTE POUR LAVABO
P130LF
P136LF / P136LF-M
Sink Hole Dimensions
Dimensiones del Hoyo Fregaderos
Dimensions des orifices de I'évier
1-1/8" Dia.
(29 mm)
(25 mm)
Allow clearance for lift rod and handle movements.
Permita un espacio para los movimientos de alzar la barra y la manija.
Laissez le dégagement nécessaire aux mouvements de la tirette et des
manettes.
86583
1
P131LF
4"
(102 mm)
1"Dia.
2"Max
(51 mm)
P135LF / P135LF-W
P138LF-M
1-1/8"Max.
(29 mm)
86583 Rev. D
