Step 3: Route & Connect
Cable To System
Connect the white RG-6 Cable to Outside Antenna and route cable
into the home. All connections should be hand tightened only.
Outside
Antenna
RG-6 Cable
A Window Entry Cable is provided to help make cable entry easier. Route
cable to the Home 4G booster and connect to top port labeled 'OUTSIDE'.
Cell
Tower
HOME 4G
CELL PHONE SIGNAL BOOSTER
Window
Entry Cable
RG-6 Cable
Outside
Antenna
Window Entry Cable
Booster
Inside
Antenna
Booster
Inside
Antenna
