Manual: Evolution Series ES-100G

7. Device connections

power switch
connection for
power supply

8. Operation

1. Connect the power cable to the device and then to the mains
2. Insert key and turn it ‚ON'
3. Press „ON" to switch on your device
4. Please make sure, that the Interlock adapter is inserted
Your device runs in auto mode:
5.
6. Your device runs in music mode:
Control the music-sensitivity by the trim pot at the front side of the device. The LED is
flashing when the device is triggered.
page 7 / 24
All manuals and user guides at all-guides.com
Interlock interface
key switch
LED signal
fan DMX in DMX out
DMX address
