Tripp-Lite SG10-RG Instructions D'installation

IMPORTANT SAFETY INFORMATION
CAUTION!
The individual user should determine prior to use whether this device is suitable, adequate or safe for the
use intended. Since individual applications are subject to great variation, the manufacturer makes no representation
or warranty as to suitability or fitness of these devices for any specific application.
Voltage Options: 12 VDC, 24 VAC/VDC, and 115 VAC
The Model SG10 is intended for use with external peripheral controls provided by the user. This model is
not equipped with a flasher circuit or switch.
CAUTION! Units with incandescent lamps require a flashing power supply or integrated flasher device to
avoid heat damage to the lens (see flasher ordering information below).
Installation:
1. Choose a location within convenient distance of a suitable power source. The power connection
can be through the underside of the housing or through the back plate. Use the ½" EMT fitting
provided, or through the back plate.
2. Using the housing as a template, mark and drill four (4) corner holes in suitable mounting location. If
mounting to brick or masonry, size the holes to accept ¼" diameter lag-type fasteners and anchors.
3. Use back plate gasket provided to secure the back plate when mounting unit to the wall.
REPLACEMENT PARTS LIST
Part# Incandescent Models
203011 Red lens w/housing
203012 Green lens w/housing
420705 Lamp, type, 25T7, 115 V
420336 Lamp, type, 1156, 12 V
423036 Lamp, type, 2223, 24 V
533004 Lamp, harness, 115 (220) VAC
533003 Lamp, harness, 12/24 VDC
553030 2-Wire Flasher
Part# All Models
203014T Yellow Housing, and rear panel
203017T Black Housing and rear panel
813008 Wall Gasket
LIMITED WARRANTY
If it appears within one (1) year from date of delivery to Purchaser that any products or component parts do not conform exactly to the specifications and physical dimensions referred
to above, and the Purchaser, at its expense, returns the product or component parts to the Seller together with a report of defects, the Seller shall review the inspection report and
inspect the items and shall authorize, at its option, either the repair or replacement of any non-conforming products or component parts, whether on warranty, contract of negligence,
shall not in any case exceed the amount to be paid by the Seller in obtaining and repair or replacement of non-conforming products or component parts, and upon expiration of the
warranty period, all liability of the Seller shall be terminated.
Incandescent bulbs incorporated into Tri Lite products are considered consumable items and are not covered by this warranty. Some Tri Lite products incorporate LED bulbs, whose
warranty is three years from date of manufacturer. Consult specific product literature for applicable warranties for Tri Lite products incorporating LED's.
Seller shall not be liable for any injury, loss or damage, direct or consequential arising out of the use or the ability to use the product. This warranty gives specific legal rights. You
may have other rights, which vary from state to state. Some states do not allow the exclusion or limitation of incidental or consequential damages, so that the above limitation of
exclusion may not apply to you.
info@triliteinc.com t: 1-773-384-7765
|
INSTALLATION INSTRUCTIONS for MODELS
SG10-RG (INCANDESCENT) and SG10-RG-LED (LED)
Part#
A16115R
A16115G
A1612R
A1612G
A1624RH
A1624GH
Part#
410403
f: 1-773-384-5115
| |
LED Models
Red signal assembly, 115 VAC
Green signal assembly, 115 VAC
Red signal assembly, 12 VDC
Green signal assembly, 12 VDC
Red signal assembly, 24 VDC
Green signal assembly, 24 VDC
All Models
1/2" EMT Fitting
www.triliteinc.com
| Designers and manufactures of specialty electrical products. Since 1922.
953063 | REV - 2/15
