Cooper Portfolio HBB2 Instructions D'installation

IB520030ML 703192
Installation Instructions – Portfolio HBB2 Hanger Bar Accessory Kit
Instructions d'installation - Trousse d'accessoires pour barre de
suspension Portfolio HBB2
Instrucciones de instalación - Kit de Accesorios para la barra de
suspensión Portafolio HBB2
INSTALLATION
Important: When using electrical equipment, basic
safety precautions should always be followed, including
the following.
For use with 2x4 construction installations (if required).
1. Remove factory installed hanger bar brackets (see
figure 1).
2. Using supplied screws, install hanger bar bracket
accessory kit as shown in figures 2 & 3.
3. To install the plaster frame, please consult
appropriate rough in instructions.
Hanger Bar Brackets
Figure 1.
Hanger Bar Accessory Kit
Figure 2.
Figure 3.
TM TM
INS # INS #
