Luminaire
Code AI18-P7X8M2BBZ5
Name PRO
Measurem.
Code AI18-P7X8M2BBZ5
Name PRO
Luminaire Flux 458.98 lm
Sources Flux 458.98 lm
2
1.5
1
0.5
0
-0.5
-1
-1.5
C90
-2
-2 -1.5
C0
LITESTAR 4D v.6 (c)OxyTech Srl www.oxytech.it
Luminaire Power 9.20 W
Maximum value 3967.33 cd/klm
Isolux (Floor)
Luminaire position X=0.00m Y=0.00m Z=2.50m
25
50
175 2 00
75 100 125
150
25
50
-1 -0.5
Efficacy 49.89 lm/W
Position C=0.00 G=0.00
50
225
50
200
25
0 0.5
Efficiency
CG Rotosymmetrical
25
1 1.5
H0V-
100.00%
V0H+
lux
2 m
