Oil Pan................................................................................................
Oil Pressure (Normal).......................................................................
Recommended Oil............................................................................
Oil Filter..............................................................................................
Valve Lash..........................................................................................
Fuel.....................................................................................................
Maximum Engine Speed..................................................................
Spark Plugs.........................................................................................
Spark Plug Gap..................................................................................
Spark Timing......................................................................................
Firing Order........................................................................................
Information may vary with application. All specifications listed are based on the latest production information available at the time of printing.
Additional Parts That May Be Needed
Harmonic Damper:
The 350/265 HP engine does not include a harmonic damper. It does include two timing tabs to use either a 6 3/4" or 8" damper. Part Number for the 6 3/4"
damper is 12551537 and for the 8" is 19301706. Use damper retaining bolt P/N 09440024 and washer P/N 14001829.
Intake Manifold:
The 350/265 HP Base engine does not come with an intake manifold. Recommended intake manifold is 10185063.
Water Pump:
The 350/265 HP Base engine does not come with a water pump. Recommended water pump P/N is 88894341.
Ignition System:
Recommended distributor is the HEI (High Energy Ignition) distributor P/N 93440806. This distributor is a self-contained ignition system that includes a magnetic
pickup, a module, a coil, a rotor, and a cap. The HEI's large diameter cap minimizes arcing and cross-firing between adjacent spark plug terminals. The cap's male
terminals provide a reliable, positive connection for the spark plug leads. However, the HEI's large diameter cap may interfere with other underhood components
in vehicles not originally equipped with HEI ignition systems. Check for adequate clearance before installation.
The HEI system requires a 12 volt power supply for proper operation. The HEI ignition system should be connected directly to the battery with 10 or 12 gauge
wire through a high quality ignition switch. If you are installing an HEI ignition in an early-model vehicle originally equipped with a point-type ignition, be sure to
remove or bypass the resistor in the wiring harness to ensure the HEI receives 12 volts continuously. Use distributor connector package P/N 12167658, which
includes connectors and wires for the HEI's tachometer and 12 volt terminals.
Set spark timing at 32º before top dead center (BTDC) at 3000 RPM with the vacuum advance line to the distributor disconnected and plugged. This setting will
produce 32º of total advance at wide open throttle (WOT). The HEI vacuum advance canister should remain disconnected. This engine is designed to operate
using only the internal centrifugal advance to achieve the correct timing curve.
Flywheel / Flexplate:
Like all small block V-8 engines produced before 1986, the 350/265 HP engine has a 3.58" diameter flywheel flange bolt pattern and uses a 2 piece rear main oil
seal design. Small block V-8 engines produced from 1958 through 1985 had a 3.58" diameter flywheel flange bolt pattern. The 350/265 HP engine must use a
zero balance flywheel/flexplate (no additional weight) for proper balance. The 350/265 HP engine does not include a flywheel or flexplate. Flywheels and
flexplates are available from the chart below.
350/265 HP Engine - Automatic Transmission Flexplates:
Part Number
00471529
00471598
350/265 HP Engine - Manual Transmission Flywheel:
Part Number
14085720
03991469
350/265 HP Engine Long Block Specifications
ALL INFORMATION WITHIN ABOVE
Date
BORDER TO BE PRINTED EXACTLY
AS SHOWN ON 8.5 x 11 WHITE 16
POUND NON-BOND RECYCLABLE
PAPER. PRINT ON BOTH SIDES,
EXCLUDING TEMPLATES. TO BE
04OC17
UNITIZED IN ACCORDANCE WITH
17JN20
GMCCA SPECIFICATIONS.
4-quart
20 psi ! 2000 RPM
10w30 synthetic motor oil (after break in)
AC Delco part # PF454 or PF1218
1/8 turn down from zero lash
Regular unleaded – 87 (R+M/2)
5100 RPM
AC Delco part # R45TS
045"
32° maximum @ 3000 RPM
1-8-4-3-6-5-7-2
Outside Diameter
12 3/4"
14"
Outside Diameter
12 3/4"
14"
Revision
Previous Revisions are
Archived
Revision Rusty Sampsel
Revision Alin Dragoiu
Converter Bolt
Pattern
9.75", 10.75
9.75", 10.75
Converter Bolt
Pattern
10.4
10.4, 11.00"
PART No.
REV 17JN20
Auth
DR
Title
350/265 HP Engine Long Block Specifications
N/A
N/A
PART No.
Starter Ring
Gear Teeth
153
For two-piece crank seal
168
For two-piece crank seal
Starter Ring
Gear Teeth
153
For two-piece crank seal
168
For two-piece crank seal
19240527
Installation Instructions
19240527
Notes
Notes
SHEET
4 of 22
SHEET 4 of 22
