OPERATING INSTRUCTIONS
MODEL: HGT6120
STOP SHOCK
OUTLET TESTER
BEFORE USE:
READ ALL OPERATING INSTRUCTIONS BEFORE USE. Use extreme caution when
checking electrical circuits to avoid injury due to electrical shock. Sperry
Instruments assumes basic knowledge of electricity on the part of the user and is
not responsible for any injury or damages due to improper use of this tester.
OBSERVE and follow all standard industry safety rules and local electrical codes.
When necessary call a qualified electrician to troubleshoot and repair the defective
electrical circuit.
SPECIFICATIONS:
Operating Range: 120 VAC, 60 Hz; CAT III 300V
Indicators: Visual Only
Operating Environment: 32° - 104° F (0 - 32° C)
Altitude up to 2000 meters. Indoor use.
Pollution degree 2. Accordance with IED-664.
Cleaning: Remove grease and grime with clean, dry cloth.
OPERATION:
1. Plug the tester into any 120 Volt standard or GFCI outlet.
2. View the indicators on the tester and match with the chart on the tester.
3. If the tester indicates a wiring problem then turn off all power to the outlet and
repair wiring.
4. Restore power to the outlet and repeat steps 1-3.
TO TEST GFCI PROTECTED OUTLETS:
1. To test GFCI (Ground Fault Circuit Interrupter) protected circuits plug tester into
GFCI protected outlet. Verify the power is on and that the outlet is wired properly.
2. Press the GFCI test button.
3. If circuit is wired properly the main GFCI outlet should trip and power to the
circuit should be off (this is indicated by the neon lamps on the tester going off).
GROUND RESISTANCE TEST:
The unit automatically tests circuits for proper ground wiring. If the resistance of
the ground wiring is greater than 7 Ohms then the red indicator on the front of the
unit will indicate a bad ground.
NOTICE:
1. All appliances or equipment on the circuit being tested should be unplugged to
help avoid erroneous readings.
2. Not a comprehensive diagnostic instrument but a simple instrument to detect
nearly all probable common improper wiring conditions.
3. Refer all indicated problems to a qualified electrician.
4. Will not indicate quality of ground.
5. Will not detect two hot wires in a circuit.
6. Will not detect a combination of defects.
7. Will not indicate a reversal of grounded and grounding conductors.
NOTICE:
1. Consult the GFCI manufacturer's installation instructions to determine that the
GFCI is installed in accordance with the manufacturer's specifications.
2. Check for correct wiring of receptacle and all remotely connected receptacles on
the branch circuit.
3. Operate the test button on the GFCI installed in the circuit. The GFCI must trip. If
it does not — do not use the circuit — consult an electrician. If the GFCI does
trip, reset the GFCI. Then, insert the GFCI tester into the receptacle to be tested.
4. Activate the test button on the GFCI tester for a minimum of 6 seconds when
testing the GFCI condition. Visible indication on the GFCI tester must cease when
tripped.
5. If the tester fails to trip the GFCI, it suggests: a.) a wiring problem with a totally
operable GFCI, or b.) proper wiring with a faulty GFCI. Consult with an electrician
to check the condition of the wiring and GFCI.
Caution: When testing GFCIs installed in 2- wire systems (no ground wire available),
the tester may give a false indication that the GFCI is not functioning properly. If this
occurs, recheck the operation of the GFCI using the test and reset buttons. The GFCI
button test function will demonstrate proper operation.
CAUTION – REFER TO THIS MANUAL BEFORE USING
THIS TESTER.
Double Insulation: The tester is protected throughout by double insulation
or reinforced insulation.
Limited Lifetime Warranty limited solely to repair or replacement; no warranty of merchantability
or fitness for a particular purpose. Product is warrantied to be free of defects in materials and
workmanship for the normal life of the product. In no event shall Sperry Instruments be liable for
incidental or consequential damage.
2150 Joshua's Path, Suite 302, Hauppauge, NY 11788
1-800-645-5398
www.sperryinstruments.com
SPERRY
GROUND RESISTANCE AND
™
80% RH max., 50% RH above 30° C
