Overview
This product is a professional, remote control, wire management system. The WMS is designed for
operating accessories (including lights, horns, warning beacons, etc.) typically used on work or off-road
vehicles (trucks, jeeps, ATV/UTV, boats, heavy equipment, farm equipment, etc.). The unit works on 12V
DC and provides output to four terminals which are protected by a 40A fuse.
Please note that the remote control can be clipped onto a visor, or conveniently stored within the
vehicle for easy access. It uses a 12V, A23 size alkaline battery included with the kit. If the
remote control is lost or broken – it can be replaced and the new remote "paired" with the existing
WMS.
Together with two flood lights, this kit will allow you to add lights for off-road in under one hour.
Installation
1. Please read these instructions carefully before installing this product. It is recommended to
consult a professional installer to prevent damage to vehicle and/or system.
2. Do not connect to 24V DC or higher voltage system, as this product is designed for a 12V DC
battery system. In case you have a larger than 12V DC system, check vehicle owner's manual to
determine if a 12V DC output is available and how to connect in order to use it safely, otherwise,
the product will be damaged.
3. Find a suitable flat surface near the battery, clean the surface free of dirt and oil and then affix the
unit using provided adhesive strips and/or mounting holes.
4. Remove the 40A fuse from the holder and disconnect the vehicle battery.
5. Securely attach the positive (red) cable of the WMS unit to the positive terminal of the battery or
battery cable and the negative (black) cable of the WMS to the negative battery cable or chassis.
6. Identify the areas where you would like to mount the LED lights and using the included hardware,
securely mount the lamp to your vehicle.
7. Securely attach the red wire of the first LED light to the positive terminal (+) of the 2A circuit on
WMS unit and black (negative) wire to the negative (-) terminal of the circuit. Repeat this step for
the second work light using the second 2A circuit. If you would like both lights to turn on at the
same time with one button push, attach both red wires to the 18A terminal's positive (+) terminal
and both black wires to the negative (-) terminal.
8. Attach the auxiliary lights/equipment following correct polarity on the terminals and not exceeding
the maximum amperage of the channels. See FIG 1 (on page 2)
9. Reconnect battery cables.
10. Insert the 40A fuse back into the holder and snap the cover closed.
11. Test by pressing remote button and checking accessory operation. Remote includes a 12V (A23
alkaline) battery. Recycle used battery as per local codes.
