set up
The In2Link is very easy to set up, simply follow the instructions below.

main hub

To attach the Main Hub, align the
USB connectors on the main hub of
the In2link with USB ports on the
PS3™ and securely push the In2link
into position (01).
Make sure
you remove
the Main
Hub from
your PS3™
Slim before
attaching
additional
modules.
01

04 | SETUP

additional modules
To add other In2link modules remove the
Main Hub from the PS3™, line up the 2
modules as shown below and click
together (02). You can now attach the
In2link Modules onto your PS3™ (03).
02
03

operation

The 'Main Hub' offers four USB ports- three neatly concealed behind a dust excluding door and another on the
side. The USB ports can be used for any USB device e.g. USB cables, wireless receivers.
infra-red receiver retractable USB
An infra-red receiver is built into The Retractable USB module
the main hub for use with infra-red attaches to the side of In2link main
peripherals. This can be used with hub by USB (see page 4).
your Gioteck MX-1 Micro Media
The cable will extend to a maximum
Remote and similar compatible IR
of 40 cm (15 inches). To extend the
remote control devices.
Mini USB cable from the In2link
pull gently (01). To retract the cable,
gently pull the cable out by an
dc charge
additional 1 cm (half an inch) and
then release.
When using high powered USB
devices (e.g. external hard drives)
or charging multiple devices it may
be necessary to connect an
external power supply (not supplied)
to the back of the In2link. The power
supply should be 1A (max)@5V DC.
01
02
OPERATION | 05
