OPERATOR'S MANUAL
CORDLESS 18 VOLT POLE SAW
This product is covered by U.S. patents and other international patents
Copyright. All Rights Reserved.
CPS40108
CPS40110
Your pole saw has been engineered and manufactured to our high standard for dependability, ease of operation,
and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
DO NOT RETURN THIS PRODUCT TO THE STORE. OPERATION, ASSEMBLY, PARTS, SERVICE QUESTIONS?
CALL 1-800-313-5111 BETWEEN 7:30 AM - 4:30 PM EST FOR ASSISTANCE.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
8458-4312002-011
2010/3/1
A4(210x297)mm
Illustrator CS3
us005
100g双胶纸
张妹珍
BATTERY MUST BE CHARGED BEFORE FIRST USE.
页 数
18张A4纸
CONTROLLED
Rev. 3
Oct. 20, 2010
