Cabin wiring to camera
The RED wire on the cable should be connected to 12V power such as a rear light unit. The BLACK
WIRE should be connected to an independent earth.
Pass the wiring harness through the cabin toward where you intend mounting the camera.
Connecting the camera
RCSW430 is a wireless system. Ensure both the monitor and camera are connected to power. If the two
have not paired automatically you will be required to trigger a manual paring process. Press the MENU
button on the monitor, and then choose
device will start pairing procedure automatically. After 1-2 seconds, power off the reversing system. Wait
3 seconds and then re-power on the reversing system and they're now paired.
Display menu setting
Adjust the brightness, color, and contrast ration, please follow the below steps.
1) Press the MENU button to enter into menu setting, use UP and DOWN button to navigate to
choose the icon.
2) Press and hold the MENU button for 2 seconds to enter into brightness, colour and contrast
ration setting.
3) Press UP/DOWN button to navigate to choose the what you want to setting, and then press
and hold the MENU button for 2 seconds to enter into setting.
4) Press UP & DOWN button to increase or decrease the set values.
5) Press the MENU button to exit setting.
Reverse image on and off setting.
1) Press the MENU button to enter into menu setting, and then press the UP/DOWN button
to choose icon.
2) Press and hold the MENU button for 2 seconds to enter into reverse image on/off setting.
3) Press UP and DOWN button to switch reverse image on/off.
4) Press and hold the MENU button for 2 seconds to flip image vertically.
5) Press the MENU button to exit setting.
Parking Lines
1) To activate the reverse parking lines, press the DOWN button.
To remove the reversing parking lines, press the DOWN button again.
13857 RCSW430 User Guide translated 4pp A5.indd 3 13857 RCSW430 User Guide translated 4pp A5.indd 3
icon, press and hold the MENU button for two seconds, the
