Back View

Detachable Antenna
Standard Reverse SMA
type connector.
Reset Button
Press the reset button 5 to10 sec-
onds to reset the configuration pa-
rameters to factory defaults.

Connecting Cables

1. To access to the Internet, connect one end of an
Ethernet cable to the WAN port of RG54SE, and the
other end to your xDSL/Cable Modem.
2. For wired connection to the network devices, connect
one end of an Ethernet cable to the LAN port (1~4) of
RG54SE, and the other end to your computers/
devices.
3. For wireless connection, install the wireless adapters
onto your computers, and you have to configure re
spective set tings on your computers (refer to your
wireless adapter's manual) to take full advantages of
the RG54SE.
LAN Ports
The RG54SE provides 4 10/
100Mbps RJ-45 ports, allowing
connection to computers and other
network devices.
WAN Port
The 10/100Mbps Ethernet
port provides connection to
your xDSL/Cable modem or
Ethernet devices.
Power Jack
C o nn e c t t h e e n c l os e d
power adapter to provide
power to the RG54SE.
1-3
