TXF-MT-01
Flange side
HMI side
Technical Data
Device
TXF-MT-01
Ident-No.
For use with
General data
Max. outside diameter of mounting tube
Min. tightening torque for mounting
– M22 hexagonal screw nut (28 mm wrench size)
– M5×10 screw (PH2 cross recess)
– Allen screw (2.5 mm wrench size)
Scope of Delivery
Part
Mounting flange
M5 Allen screw
O-ring seal
Ring seal
M22 hexagonal screw nut
M5×10 screw
M5 spring washer
100020090
TXF705
TXF707
TXF710
48 mm, + 0 mm/- 0.3 mm
1000 Ncm
130 Ncm
Quantity
1
4
3
1
1
4
4
© Hans Turck GmbH & Co. KG | 100021099 2020-08
