ii. Place the small unit on the movable door with the small unit aligned near
iii. The spacer is used in situations where the smaller piece needs to be
b. On your window:
i. After selecting a location on the window, the large unit of the sensor
ii. Place the small unit on the movable window with the small unit aligned
iii. The spacer is used in situations where the smaller piece needs to be
4. When you open and close the doors and windows, the two parts should separate when
opened and then come back together when closed.
5. Verify that the two pieces are functional by noting that the LED on the sensor piece
blinks on/off when the parts are seperated. The LED on the sensor piece blinks on/off
again when the parts are placed together again.
*Note: If your door or window does not allow you to properly place the large unit of the
sensor on the frame, it is acceptable to place the smaller unit of the sensor on the frame to
make the placing easier. This is an acceptable approach to sensor placement, although it
should only be used when necessary.
the top half of the large unit and not exceeding the recommended width
of a pencil or a quarter of an inch between the sensors for best
performance.
elevated to the larger piece to ensure proper contact.
should be placed on the immovable window frame.
near the top half of the large unit and not exceeding the recommended
width of a pencil or a quarter of an inch between the sensors for best
performance.
elevated to the larger piece to ensure proper contact.
