Quick Start; The Main Wash - RCA RPW210 Manuel D'instructions

Quick start

1 Install the washing
machine
2 Load the laundry
3 Measure out the
detergent
4 Close the top lid
5 Hang up the drain
pipe firmly
Programme selection
1
Press the ON/OFF button.
2 Select the proper water level and other attached functions.
Press the Start/Pause key.
3
The wash stops
When the wash stops, the buzzer will buzz continuously for 6 times and
then the power will be automatically cut off.
Turn off the water tap.
Although the power can be cut off automatically, the power plug must be pull
out for the safety.
9 Press the
[start/pause] key
8 Select the desired
program
7 Plug the power supply
6 Turn on the water supply
12

The main wash

Instruction of the Heavy procedure
! [ Heavy ] wash program is the easiest, most convenient and most common washing
program. When the user press the power switch and then press [Start/Pause] button,
the Heavy washing program will start to work.
! When the washer start to work, the digital tube show the remain time. The indicator
light which stand for remaining time is flickering.
Steps in details
ON/OFF
1.Press the button.
2.According to the washing amount choose the proper water level.
3.Press Start/Pause button.
Instruction to single wash procedure
! User can freely select any single procedure, or any combination of procedures
among Wash, Rinse and Spin according to the actual requirements. It is only
required to turn off any one or two of these three indicators that not needed by the
user. And keep the indicator be on showing the process needed by the user.
! Single wash -- after switching on the power, turn off Rinse and Spin two indicators
by pressing these two keys. The operation for single rinse and single spin is similar.
! Single wash-spin – after switching on the power, turn off Rinse indicator by pressing
that key. The operation for single rinse-spin and single wash-rinse is similar.
Use the cleaning solution for twice
1. Put the laundry in the first batch and wash powder and press "Function" button to set
single "wash" to run.
2. Take out the laundry in the first batch after hearing the buzzing sound.
3. put in the laundry in the second batch, and run " Wash", "Rinse", "Spin".
4. Take out the laundry in the second batch after hearing the buzzing sound.
5. Put in the laundry in the first batch and press " Function" button to run "Rinse" and "Spin".
！
NOTICE
! Close the lid of the door when machine is running, otherwise, it will automatically
stop working during spin process and send out abnormal warning.
!The washer will not work when the filled water does not reach the set water level.
13
