Parts List
M6 x 16mm Posidrive
60616
6mm Stainless Steel Washer
60065
Neoprene washer
60521
M5 x 20mm Pin torx
60523
5mm silicone washer
60519
Helm Pod Back + Seal
Helm Pod Front
Expanded Polyethylene Seal
190SPH1 (190SPH2 for 2i & 4i Pods)
1
4
7
*15" (9), 2i (6), 4i (8)
Qty.
2
60517
Hole Saw
ø20-25mm (1")
5
Scanstrut Scanpod Installation Instructions
Tools Required
4
Tap Wrench
4
No.3 Posidrive
4
Power drill
7*
7*
Tools Included
1
1
2
60518
ø5.0 mm drill bit
M6x1.0mm tap
T25 Pin torx Key Wrench
3
6
8
9
63516
INSTALLATION SOLUTIONS FOR MARINE ELECTRONICS
Helm Pod
Jigsaw/Spiral Saw
Hole Saw
ø20-25mm (1")
(60517)
(60518)
(63516)
60521
60616
4 x
4 x
60065
4 x
60523*
7 x
60519*
7 x
®
Publicité
Sommaire des Matières pour Scanstrut Scanpod
- Page 1 Scanstrut Scanpod Installation Instructions Helm Pod Parts List Qty. Tools Required M6 x 16mm Posidrive Tap Wrench Jigsaw/Spiral Saw 60616 6mm Stainless Steel Washer Hole Saw No.3 Posidrive ø20-25mm (1”) 60065 Neoprene washer Power drill 60521 M5 x 20mm Pin torx...
- Page 2 IMPORTANT Helm Pods are only compatible with marine electronics devices as stated in the latest Scanstrut Product Guide – subject to change without prior notice. Use with unapproved products, or overloading, invalidates any warranty. No liability is accepted for damage caused by incorrect installation.
