Using The System; Radio Controls - ECG RB 040 Mode D'emploi

• Do not expose the device to heat sources such as radiators, heating or other heat-producing appliances
such as amplifiers.
• Changes or modifications not expressly approved by the responsible authority can lead to loss of
authorization to use the device.
DESCRIPTION
View from above [A]
1. SNOOZE/SLEEP/DIM button
2. ON/OFF/NAP button
3. "P-" button
4. ALARM1/VOL- button
5. HOUR/TUNING- button
6. TIME/PRESET button
7. "P+" button
8. ALARM2/VOL+ button
9. MIN/TUNING+ button
Rear view [B]

USING THE SYSTEM

GB
Preparation for use
This alarm radio is equipped with backup power, which in the event of
a brief power outage keeps the setting of the clock and alarm. Insert
two AAA batteries in the battery compartment 0, observe correct
polarity (+) and (-) marked inside the battery compartment. If there is
a power outage and batteries are inserted in the device, the display of
the alarm radio goes off, but the clock is still running and retains the
set alarm. Replace discharged batteries both in the same time with
new batteries of the same type.
The alarm radio is equipped with non-slip silicone pads. Do not place
the alarm radio on furniture with sensitive surface, which can be
marked by the non-slip pads.
Plug the cable qs in the electrical outlet.
Alarm radio controls
Setting the time
Note:
• If after plugging it into power outlet the clock display flashes,
you cannot activate any function. Press 6 (TIME/PRESET) to
stop the flashing and start setting the clock.
• You can set the clock of the device only when the radio is off.
Press 2 (ON/OFF/NAP) to turn off the radio.
• When clock display is flashing you cannot turn on the radio by
pressing 2 (ON/OFF/NAP).
1. Press and hold (for 3 seconds) 6 (TIME/PRESET) so that the
display starts flashing.
2. Press repeatedly 5 (HOUR/TUNING-) to set the hour.
3. Press repeatedly 9 (MIN/TUNING+) to set the minutes.
4. Press 6 (TIME/PRESET) to confirm the setting, display stops
flashing.
Setting alarm
This alarm radio allows you to set two independent wake-up times.
The process to set the alarm time is the same for both alarms. Both
alarms can be set for wake-up either by buzzer or by radio.
Note: You can set the alarm time only when the radio is off. Press 2
(ON/OFF/NAP) to turn off radio.
1. If you want to set the 1st alarm for wake-up by buzzer, press
4 (ALARM1/VOL-), so that the indicator E ( ) starts flashing.
If you want to set the 1st alarm for wake-up by radio, press 4
(ALARM1/VOL-) twice so that the indicator F ( ) starts flashing.
20
10. Battery compartment
11. FM antenna
12. AC power cable
Front view [C]
A. Time and radio frequency display
B. 2nd alarm indicator – buzzer
C. 2nd alarm indicator – radio
D. FM indicator
E. 1st alarm indicator – buzzer
F. 1st alarm indicator – radio
2. When the numbers are flashing, set hours by repeatedly pressing
the 5 (HOUR/TUNING-) button, by pressing repeatedly the 9
(MIN/TUNING+) button, set minutes.
3. Confirm the set time by pressing 4 (ALARM1/VOL-).
4. If you want to cancel the alarm, press three times the 4
(ALARM1/VOL-) button while displaying current time. The alarm
indicator disappears from the display.
5. When the alarm starts you can press 4 (ALARM1/VOL-) to turn
it off or press 1 (SNOOZE/SLEEP/DIM) to go into snooze mode
(SNOOZE). In this mode the symbol
sounds again in 5 minutes.
6. You can set the second alarm the same way, but instead of the
button 4 use the button 8 (ALARM2/VOL+).
Note: You have to set the time and the alarm while the numbers on
the display are flashing. After about 10 seconds of inactivity,
the display stops flashing.

Radio controls

Basic operations
1. Press 2 (ON/OFF/NAP) to turn on the radio.
2. Use the button 5 (HOUR/TUNING-) or 9 (MIN/TUNING+) for
manual tuning to increase or decrease the frequency in steps by
0,10 MHz.
3. When using automatic tuning, press 5 (HOUR/TUNING-) or 9
(MIN/TUNING+) and hold for about 3 seconds. When you release
the button, the device starts to search for the closest previous or
next radio station.
4. Using buttons 4 (ALARM1/VOL-) or 8 (ALARM2/VOL+) set
volume. While adjusting the volume, the display changes to
show the volume (range 00-14), then goes back to show the
frequency and subsequently the current time.
5. Press 5 (HOUR/TUNING-) or 9 (MIN/TUNING+) to display the
radio station's frequency.
Presets of radio stations
1. The device allows you to store up to 20 radio stations in memory.
2. If you want to store a radio station in memory, first tune to the
desired station. Then press and hold for about 3 seconds the
button 6 (TIME/PRESET) "P01" on the display starts flashing.
Using 7 (P+) or 3 (P-) select the required memory position
(P01 to P20) and confirm by pressing 6 (TIME/PRESET).
3. You can perform the above mentioned steps for up to 20 radio
stations.
or will flash. The alarm
