Door Alignment - RCA RFRF300 Manuel De L'utilisateur

FREEZER FEATURES AND USE CONT.
LEVELING YOUR FREEZER
• Your freezer has two leveling legs which are located in the front bottom
corners of your freezer. After properly placing your freezer in its final
position, you can level your freezer.
• Leveling legs can be adjusted by turning them counterclockwise to raise your
freezer or by turning them clockwise to lower your freezer. The freezer door
will close easier when leveling legs are extended.

DOOR ALIGNMENT

1. Remove the top hinge cover using a flat
head screw driver. Gently lift from the
rear of the hinge and slide forward.
2. Lossen the top hinge screws using a Phillips
head screwdriver.
3. Adjust the door or put a spacer in between
and then tighten the screws.
4. Replace the top hinge cover by aligning
the rear of the cover with the rear of the
hinge. Press firmly on the front of the cover
until it snaps in place.
8
