Diagram and Parts Description
11 11
WORLD ROCKER WORLD ROCKER
1. Instrument/ Microphone Input with Volume Control
(1/4"): This mono input accepts a 1/4" input such as a
microphone, guitar, or other musical instrument.
2. Auxiliary input: This stereo 1/8" input can be used to
connect a CD player, MP3 player, or other audio source.
3. Bluetooth: The Paired LED will be lit when a device is
paired to World Rocker. This LED will not be lit when World
Rocker is first powered on (unless it was previously paired
with a device). Press the Disconnect button to disconnect a
paired Bluetooth device.
4. Master Volume Control: This adjusts the speaker's main
mix volume, which includes Instrument/Microphone Input,
Auxiliary Input, Tuner, and the audio of a paired Bluetooth
device.
5. Radio Selector: This switch sets the tuner to AM or FM or
turns the tuner off. (Note: This switch does not turn the
unit's power off – just the tuner.)
6. LCD: Displays the current radio station.
7. Tuner: Use these buttons to search for a radio station. To
"seek" (jump to the next available station), hold this down for
a few seconds until it starts to seek a station. Unit will
remember the last station you were on when you
power off and power back on.
8. Power LED: Indicates whether World Rocker is on or
off.
9. USB Charge Port: Connect your devices charge
cables to these ports to charge them. USB charging
only functions when the unit's power is turned on.
10. Device Cradle: Place your iPad/iPod touch/iPhone,
Android or other device here to be held. These can be
connected via Bluetooth or to aux input using the
included 1/8" to 1/8" cable.
Note: It is recommended to remove your iPad or other device from the cradle before transporting or
traveling with World Rocker.
11. NFC: Tap your NFC (near-field communication) supported and enabled device here to pair your phone
by gently bumping on the 'N' logo. See the section Pairing with a Device using NFC for more
information.
9
1
2
10 10
5
3
4
*WARNING: If your unit has a voltage
selector switch, change its setting only
when necessary (e.g., when traveling to a
country or region with a different voltage).
Selecting an improper voltage setting can
damage the unit. To change its setting,
only remove *one* screw of the cover and
slide it aside to expose the selector.
4
12 12
8
6
7 7
WORLD ROCKER WORLD ROCKER
16 16
13 13
15 15
14 14
