Smoothtalker Stealth X6 4G LTE Mode D'emploi

LED Lights Indicate Gain Status
Lumières DEL indiquent l'état de gain
Attenuation - Atténuation (Att)
Each ash indicates up to 3dB of gain reduction also known as gain attenuation.
For example: three ashes equals 9dB of attenuation.
Chaque ash indique jusqu'à 3dB de réduction de gain aussi connu comme
atténuation de gain. Par exemple: trois clignotements égal 9dB d'atténuation.
Orange Solid ON = Full Gain & Green Solid ON = Full Gain
No Flashing = Full Gain
Orange Allumé Solide = Plein Gain & Vert Allumé Solide = Plein Gain
Non clignotant = gain plein
Orange Solid ON & Green Slow Flashing = Oscillation Att
Each Flash = up to 3dB gain reduction
Orange Allumé Solide & Vert Clignotement Lent = Oscillation Att
Chaque ash = jusqu'à 3dB de réduction de gain
Orange O & Green Fast Flashing = Oscillation Shutdown
Fast Flashing = booster shutdown (pls troubleshoot)
Orange Éteinte & Vert Clignotement Rapide = Désactivée de l'Oscillation
Clignotant rapide = ampli cateur fermé (s'il vous plaît dépanner)
Orange Slow Flashing & Green Solid ON = RX High Power Att
Each Flash = up to 3dB gain reduction
Orange Clignotement Lent & Vert Allumé Solide = RX Haute Puissance Att
Chaque ash = jusqu'à 3dB de réduction de gain
In 2001 SmoothTalker produced the rst digital mobile cellular signal booster
in North America with FCC and ICAN approval. We continue to lead with the
most powerful and intelligent boosters in the world.
Our dynamic adaptive proprietary algorithms make them very network friendly.
We call it STEALTH TECH technology.
En 2001, SmoothTalker produit le premier ampli cateur de signal cellulaire
mobile numérique en Amérique du Nord avec l'approbation de FCC et ICAN.
Nous continuons à mener avec les amplis les plus puissants et intelligents dans
le monde. Nos algorithmes propriétaires adaptatifs dynamiques rendent très
réseau amical. Nous appelons cela la technologie STEALTH TECH.
Made in
Industry
Canada
Canada
Approved
Approuvé par
Fabriqué au
Industrie
Canada Canada
1-877-726-3444
Understanding the LED Indicators
The LED lights on the booster face plate indicate the operating gain state
of the booster.
The Green and Orange lights indicate the gain status in each operating band
When Both Green and Orange LED's are "SOLID ON" it means that the booster
is operating normally with full gain (No Automatic Gain Reduction)
When one or both of the LEDS are ashing (Per the chart on back page)
it indicates that the gain has been automatically reduced due to either:
A) High RX outside signal level (close to cell tower)
B) Loop Oscillation, caused when the inside antenna is located too close to the
outside antenna.
Optional Dual Inside Antenna Installation (Fig. 2)
(Additional parts required which are not included in Booster kit
1) Choose a splitter model for your needs. For 2 interior antennas use a 2 way
splitter and for 3 interior antennas use a 3 way splitter etc...
2) Mount the interior antennas in the areas which need cellular coverage
3) Evenly distribute the antennas throughout the oors and areas to cover
4) Turn on Booster unit and check signal strength improvement as needed
If you need help pls contact techsupport@smoothtalker.com and we will help
you determine your cell tower location and get you setup.
techsupport@smoothtalker.com
3
ORANGE LED GREEN LED
High Power Oscillation
haute puissance
ON/ ON/
Allumé Allumé
Solid On-Allumé Solide Solid On-Allumé Solide
ON/
Allumé
Slow Flashing
Solid On-Allumé Solide
Clignotement Lent
OFF/
Éteinte
Fast Flashing
Clignotement Rapide
ON/
Allumé
slow ashing Solid On-Allumé Solide
clignotement lent
stealth
Automatic power
control protects the
tech
®
Cellular Network
Smoothtalker.com
RX High Power Attenuation
Oscillation Attenuation
Band Frequency
Band 12, 17 700MHz Lower
Band 13 700MHz Upper
Band 5 850MHz
Band 4 1700/2100MHz
Band 2, 25 1900MHz ext
Green LED
Orange LED
Tel: 1 877 726 3444
Stealth X6 4G LTE
Extreme Power Building Boosters X660 X665 X670 X672
Amplificateur Bâtiment Puissance Extrême X660 X665 X670 X672
User Manual- Manuel de l'utilisateur
Cellular
60-72dB 6 BAND
RX/TX
Signal Booster
MULTI BAND 60-72dB
Extreme Power Building Booster
Amplificateur Bâtiment Puissance Extrême
2G, 3G, 3G+, 4G, 4G+
GSM,HSPA,CDMA,LTE, LTE A
Band 12,17 700MHz Lower
Band 13 700MHz Upper
Band 5 850MHz
Band 4 1700/2100MHz
Band 2,25 1900MHz ext
1-877-726-3444
LED Lights Explanation and Troubleshooting
Each ash indicates 3dB of gain reduction also known as gain attenuation.
For example: three ashes equals 9dB of attenuation.
Green LED indicates loop oscillation status. When ashing it means reduction of
gain. To improve you need to spread the distance between the inside and outside
antennas. If you spread them far enough away, the Green LED
will become SOLID ON.
Orange LED indicates RX (outside signal) status.
There are 5 Orange LED lights: 700 Mhz Lower, 700 Mhz Upper, 850 Mhz,
1700/2100 Mhz,1900 Mhz ext. LED ON state indicates that the RX (Receive Signal)
function of the band is functioning normally.
LED OFF state indicates that the band is shut down.
When Orange LED is ashing it indicates reduced gain also known as attenuation
of gain. You cannot prevent this condition. It means that the outside signal is very
strong and the booster has reduced it's gain in order to protect the closest cell
tower. If the cell tower which is close is the one you are using, then you can ignore
the gain reduction and you will still get enough signal strength to cover your area.
In this case this is the normal operating process.
If the close cell tower is not the one you are using, then you can try to relocate
your outside antenna away from this cell tower and face it or point it to the cell
tower you are using in order to get more gain.
Installation optionnelle d'antenne intérieure double ( gure 2)
(Pièces supplémentaires nécessaires qui ne sont pas incluses
dans le kit Ampli cateur.
1) Choisissez un modèle diviseur pour vos besoins. Pour 2 antennes intérieures
utiliser un diviseur 2 voies et pour 3 antennes intérieures utiliser un diviseur
3 voies etc ...
2) Montez les antennes intérieures dans les zones qui ont besoin d'une
couverture cellulaire
3) Distribuer uniformément les antennes à travers les étages et les zones à couvrir
4) Allumez l'unité Ampli cateurr et véri ez l'amélioration de la puissance du signal
comme requis
Si vous avez besoin d'aide, veuillez contacter techsupport@smoothtalker.com
Et nous allons vous aider à déterminer l'emplacement de la tour cellulaire et vous aider à con gurer.
6 BAND
MULTI BAND
60 -72dB
Multi Bandes
à 6 BANDES
BBCX6 Series
Canada
model shown: BBCX660
stealth
tech
®
Smoothtalker.com
