BT7382
FULL MOTION DESK MOUNT WITH SINGLE ARM
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Desk Mount
PLEASE KEEP THIS FOR FUTURE REFERENCE
REGISTERED DESIGN NO. 001713280-0042
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Product Dimensions..........................................................................................................................15
B-Tech Contact Details.....................................................................................................................16
INSTALLATION TOOLS REQUIRED
Crosshead
screwdriver
B-TECH AUDIO VIDEO MOUNTS
FEATURES
Designed for screens up to 24" (61cm) / 9kg (20lbs)
Fits screens with VESA mounting patterns:
75 x 75mm and 100 x 100mm
Optional desk clamp and grommet included
Maximum extension is 390mm (15.4")
Easy tilt adjustment +/-40° tilt
Features two swivel points: 360° at pole and 180° at interface
Simple installation with all mounting hardware included
CONTENTS
2.5mm Hex Key
(Supplied)
www.btechavmounts.com
4mm Hex Key
(Supplied)
Publicité
Sommaire des Matières pour BTECH BT7382
- Page 1 BT7382 FULL MOTION DESK MOUNT WITH SINGLE ARM INSTALLATION GUIDE & PARTS LIST This Pack Contains 1 Desk Mount PLEASE KEEP THIS FOR FUTURE REFERENCE FEATURES Designed for screens up to 24" (61cm) / 9kg (20lbs) Fits screens with VESA mounting patterns:...
- Page 3 Spoleþnost B-Tech International Ltd. doporuþuje provést instalaci tohoto produktu prost ednictvím odborného instalátora AV þi jinak zp sobilé osoby. Spoleþnost B-Tech International Ltd, její distributo i a prodejci nenesou odpov dnost za škody nebo zran ní zp sobená nevhodnou instalací. Tento výrobek je nutno umístit do vhodné konstrukce a pouåtvat jen po uvedenou maximální...
-
Page 4: Parts List
BT7382 PARTS LIST GROMMET CLAMP Suitable for loads up to 9kg (20lbs) - Page 5 PART NAME HEIGHT ADJUSTMENT COLLAR RECTANGULAR FOAM PAD 2.5mm HEX KEY (FOR PART10) 4mm HEX KEY (FOR PARTS 9 & 11) INTERFACE KIT PLEASE KEEP THIS FOR FUTURE REFERENCE...
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Choose a preferred mounting method. i. Clamp (page 6) ii. Grommet (page 8) i. Desk clamp option. Max 70mm (2.8") - Page 7 Attach the foam pads to the underside of the clamp base. Place the mount over edge of the desk and tighten the short handwheel. DESKTOP...
- Page 8 ii. Grommet Clamp Max 95mm (3.7")
- Page 9 Remove the desk clamp and attach the grommet plate. Then attach the foam pads onto the grommet plate. Place the mount over the cable management hole and screw the handwheel into the grommet plate, then tighten the nut to clamp the desk. DESKTOP...
- Page 10 Attach the interface plate to the flat screen. FLAT SCREEN To lock height of adjustment collar, hold the top of the collar and rotate the lower part of the adjustment collar. LOCK COLLAR...
- Page 11 Slide the flat screen and arm onto the pole, adjust height, then tighten the grub screw. FLAT SCREEN iii. LOCK COLLAR UNLOCK COLLAR...
- Page 12 OPTIONAL: Cable Management. Insert the cable into the cable management slots on the underside of the arm. WARNING: Ensure arm is fully extended before FLAT connecting cables. SCREEN CABLE CABLE CABLE CAUTION: Ensure there is adequate cable slack for movement of the screen, and that cables will not be pinched when the mount is closed.
- Page 13 Tighten/loosen the allen screw on the articulating arm to adjust the resistance for tilt. ° +/- 45...
- Page 14 Tilt and swivel. 360° +/-90° If the interface does not hold the screen at the required tilt, remove the flat screen from the interface. Then remove plastic nut cover and tighten the M8 nyloc nut. +/-40° M8 nyloc nut...
- Page 15 BT7382 PRODUCT DIMENSIONS 390mm 15.4" 408mm 16.1" 45° 45° 35mm 1.4" INTERFACE PLATE DESK CLAMP, GROMMET & BASE 169mm 6.7" 100mm 3.9" 75mm 3" 83.7mm 72mm 3.3" 2.8" 120mm 4.7" THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO...
- Page 16 B-Tech Audio Video Mounts is a division of Bennett Technologies Limited. B-Tech and Better By Design are registered trademarks of Bennett Technologies Limited. All other brands and product names are trademarks of their respective owners. Photographs are for illustrative purposes only. E&OE. IP-BT7382-V1-PROBX-180511-21 MADE IN CHINA...
