System Map: Front, Left & Right Views
1
Figure 4 - Front, Left & Right Views
1. LED Indicators
2. Vent
3. External Monitor Port
4. HDMI-Out Port
5. USB 3.0 (USB 3.1 Gen 1) Type-C Port
6. USB 3.0 (USB 3.1 Gen 1) Type-A Port
7. USB 2.0 Type-A Ports
Front
Left
2
3
Right
7
8
9 10
8. Multi-in-1 Card Reader
9. Headphone-Out Jack
10. Microphone-In Jack
11. RJ-45 LAN Jack
12. DC-In Jack
13. Security Lock Slot
7
4 5 6
12
11
To prevent your com-
puter from overheat-
ing make sure nothing
blocks any vent while
the computer is in use.
13

Overheating
9
