appliance Caution! Four sharp needles
GB
OvervieW
open the capsule in the
machine. To avoid injury, do
1 Drip grid not reach into the capsule
2 Top drip tray insertion slot.
3 Bottom drip tray
4 Capsule collection
container
5 Beverage buttons,
hot water button
3
6 Capsule insertion slot
2
1
7 On/off button
8 Lever
9 Water tank
10 Water filter
11 Outlet
Risk of scalding!
The appliance
produces very hot
water (when preparing tea
and milk, descaling, cleaning
and rinsing). To avoid scalds
or other injuries, always make
sure that the lever is com-
pletely closed when the ap-
pliance is running. Do not
reach under the outlet and
do not remove the bottom
drip tray.
Please check that the package is complete before
using the appliance. The package also includes one
water filter and two cleansing capsules.
6
7 8
6
5
4
11
Remove the protective film from the drip grid
(1) before the first use.
For cream coloured
9 capsules (milk, with-
out aroma seal)
For cream coloured
capsules (chai)
For red capsules
(fruit tea)
Buttons
On/off button
Chai latte
10
Hot water button
Black tea
Green tea
Herbal/fruit tea
For black capsules
(black tea)
For green capsules
(green tea)
For yellow capsules
(herbal tea)
Light signals
Button illuminated white: ready for operation;
the button can be pressed.
Button flashes white: please wait. Either the
appliance is heating up, is delivering a beverage
or is rinsing.
Button flashes white and rapidly: the filling
quantity is being programmed (see page 11).
Hot water button flashes red: error message.
Key
GB
assignmenT
7
